Hatch, Anchor and Rudder Position-Sensing Using Reed Sensors

Hatch, anchor and rudder positions on boats and yachts need to be monitored. In the realm of advanced sailboats and yachts, the integration of sophisticated microprocessor systems control navigation and other mechanisms. These centralized systems autonomously determine optimal rudder and keel positions based on predefined courses, dynamically adjusting motorized rudders to steer the vessel along its intended trajectory. To verify the accuracy of these adjustments and ensure alignment between requested and actual rudder positions, a robust feedback system is imperative.

Multiple magnet sensors, strategically positioned with magnets affixed to the rudder mechanism, form the backbone of this feedback mechanism. By meticulously tracking the movement of the rudder, these sensors provide real-time data to the central processor, enabling precise course correction and navigation.

Furthermore, magnet sensors offer versatile applications beyond navigation feedback systems. Simpler tasks such as verifying the full deployment of an anchor or ensuring the closure of hatches are seamlessly addressed through the integration of magnet sensors and corresponding actuating magnets. This intuitive combination facilitates efficient monitoring and control of auxiliary functions, enhancing overall safety and operational efficiency aboard sailing vessels.

In essence, the integration of magnet sensor technology represents a cornerstone of modern sailing, facilitating precise navigation, control, and monitoring capabilities across a broad spectrum of vessel types and operational scenarios.

Application Classification

Applications are classified as Position Sensing, Pulse Counting, Electromagnetic or Relay, Temperature Sensing or Magnet Biasing types. This application is classified as follows and the link gives more information on best practices to help select the most suitable AT band and matching magnet.

Position sensing Type

When an application requires the end position of a movement sensed, or the sensing of a part when it comes into a zone, or when the Continue reading -> Sep 29, 2024

Recommended Products

The Reed Switches and Sensors used in such applications need to be robust, durable and efficient in meeting a high life expectancy. Our engineers work hard in life testing our products under various conditions, and our intention is to ensure end product durability and life. Although we wouldn’t want to restrict any of our products for use in only certain applications, the recommended products for use in this application are listed below.

Standard PCB Mountable Reed Sensor, MS-108

Drawing of MS-108 Reed SensorDrawing of MS-108 Reed Sensor Pad Layout starFeatures10W Contact Rating. 20.3 mm PCB Pitch. Normally Continue reading -> Sep 3, 2024

M8 Threaded Sensor Cylindrical Sensor, MS-228

MS-228 M8 Threaded Sensor Drawing starFeatures30W Contact Rating. Normally Open contact. Three sensitivity bands. Sputtered Ruthenium Continue reading -> Sep 28, 2024

Line Voltage switching Reed Switch, LV-1925

Full Length LeadsCropped LeadsSMD Formed LeadsVertical MountingHorizontal Mounting starFeaturesContact Rating Configurable. Ruthenium Continue reading -> Sep 3, 2024
